Foxwell GT80 Next Generation Diagnostic Scan Tool

Download

gt80-plus-user-manuel.pdf

Foxwell GT80 Next Generation Diagnostic Scan Tool

Foxwell GT80 General Description:
GT80 is a Window 8 based universal diagnostic scan tool. It's coverage includes 58 vehicle brands and it has access to trouble codes, live data stream and bi-dirctional controls on all control modules (ABS, airbags, instrument cluster, etc.). In addition, it has access to the most commonly required service features like brake deactivation, service resets, and transmission adaptations and more.
Foxwell GT80 Update : 1 Year for free, after 1 year, it will cost 400USD/year

Foxwell GT80 Most Important Features:

Ease of use, unique live data self-studay and compare, coding and programming, 58-brand coverage, automatic vehicle identification by VIN, 10.1” TFT color capacitive screen with resistive touch panel


Target Customer Groups:
Workshops, garages, training schools, service chains, independent repair shops, professional technicians, enthusiasts etc.Foxwell GT80 qc mark

Professional Level

The most professional scan tool of our range and technical supports are required. Distributors must have a strong diagnostic/technical background.

What Can Foxwell GT80 Do:
Compatible with both OBDI and OBDII cars, SUVs, minivans, light-duty trucks sold worldwide
Compatible with the latest 2015/2016 models
Get access to powertrain, chassis and body systems
Quick Test function automatically scans all diagnosable electronic control units on a vehicle, instantly displays all the errors detected on the vehicle along with codes and descriptions, and allows errors to be viewed and erased with a single click.
Read and clear diagnostic trouble codes and reset MIL
View live vehicle sensors data in a text, graph and gauge format
Merge interactive live sensor graphs for easy and intuitive diagnosis
Live data self learning and alarm when live data over range
Record and playback your data logs for offline analysis
Read and clear freeze frame data
Run component/system bi-directional tests
Support adaptations and control module coding
Key coding for several vehicles
Support the most commonly required service features like brake deactivation, service resets, and     transmission adaptations

Foxwell GT80 Support Language:

English, Spanish, German, French, Portuguese, Dutch, Swedish, Italian, Simplified Chinese, Traditional Chinese, Russian, Japanese, Korean, Polish, Hungarian and Thai

Foxwell GT80 Vehicle Coverage:


USA Coverage:
Chrysler,Ford,GM,Brazilian GM (For Brazilian Market Only)


ASIA Pacific coverage:
Acura, Brilliance, BYD, Chery, Daewoo, Geely, Great Wall, Honda,  Hyundai, Infiniti, Isuzu, JAC, Kia, Lexus, Mazda, Mitsubishi, Nissan, Perodua, Proton, Scion, Subaru, Suzuki, Toyota

European Coverage:

Audi, Bentley, BMW, Bugatti, EU Ford, Jaguar, Land Rover, Maybach, Mercedes Benz, Mini, Opel, Porsche, Rolls-Royce, Saab, Seat, Skoda, Smart, Sprinter, Vauxhall, Volvo, VW

French & Italian Coverage:
Abarth, Alfa-Romeo, Citroen, Dacia, Fiat, Lancia, Maserati, Peugeot, Renault

Feature-Live Sensor Data:

Live sensor data is the key of determination of the real causes of car failures. To address the needs, Foxwell did a lot of work to make the best live data function of the industry. *Shows live vehicle sensors data in text, graph and gauge format, allows you to focus on any suspicious or symptom-specific data parameters.
*Allows to view up to 4 parameter graphs simultaneously and merging multiple PID plots into one coordinate, providing the most comprehensive and functional look at live data possible.
*Learns and records good live sensor data values, compares with the faulty sensor and parameter readings to the good readings and warns the technician of the faulty sensor data. There might be hundreds of live data parameters in a car, and it is almost not possible for even the most experienced technician to remember the correct value of every and each parameter. GT80 provides such useful function that every technician would like.
* Records hours of live data stream and playbacks the recording to make sure you capture the intermittent fault whenever it happens.

Foxwell GT80 Package List:

1pc x GT80 Plus Main Unit
1pc x Mercedes Benz 38 Pin Adapter
1pc x Toyota 17 Pin Adapter
1pc x Honda 3 in Adapter
1pc x Mazda 17 Pin Adapter
1pc x OBDII Adapter
1pc x Toyota 22 Pin Adapter
1pc x AUDI 4 Pin Adapter
1pc x BMW 20  Pin Adapter
1pc x GM/Daewoo 12 Pin Adapter
1pc x Kia 20 Pin Adapter
1pc x Mitsubishi 12+16 Pin Adapter
1pc x Nissan 14 Pin Adapter
1pc x Fiat 3 Pin Adapter
1pc x PSA 2 Pin Adapter
1pc x Diagnostic Cable
1pc x Clip Cable
1pc x AC/DC External Power Cord
1pc x Cigarette Lighter

1pc x AC/DC External Power  Adapter

1pc x User Manual

FAQ:
 Q: Are both Foxwell GT80 and GT80 Plus models are similar and use same accessories like cables and adapters?
  A:   GT80 and GT80 Plus accessories is same. Only differs in main unit and appearance. GT80 PLUS contain inside battery.
  Q:Do these GT80 scanners use standard 15pin male/female data cable or is it unique cable? I mean by standard cable is that the cable is same pin to pin connected between the male connector and female connector 1-1, 2-2, 3-3, etc...

A: GT80 use stanard 16-pin cable, not unique.
